Double-Head High Frequency Welding Machine

Double-Head High FrequencyWelding Machine-Technical Data: Model: NK-GJ0043 HF Output: 4KW/5KW/8KW Vibration frequency: 27.12mMHZSupply voltage: AC380V Max input power: 6KVA/8KVA/12KVA Oscillating: E3062/7T85RB/7T69RB Rectifying tube: HVP-14 Maximum pressure: 90kg/90kg/1.5T Lower pole plate: 350*700/350*700/450*800mm Travel distance: 60/60/70mm Mode of pressurization: Foot operated Double-head High Frequency Welding Machines-configuration: 1.Imported oscillating tube, with stable, reliable output 2.High-sensitivity spark arrester, protecting molds effectively 3.Overload protector 4.Key electric assemblies assembled from imported high-quality parts Double-head High Frequency Welding Machines--Functional description: 1. High-sensitivity spark protection: This unit is equipped with a special electronic circuit that cuts off high frequencies to arrest sparks, minimizing the damage to the electrode and material, while the warning lamp gives an alarm. 2. Wave interference protector: A frequency stabilizer and a high-frequency magnetic leakage arrester are provided to prevent wave leakage from interfering with other electronic devices. 3. Overload protector: Avoiding frequency drift as a result of improper operation 4. Strong head: Strong enough for any situation, handy and precise to use5.Adjustable tuner: Output power can be adjusted at the tuner according to electrode size and material thickness. Required welding time has been cut down greatly to raise the machine's productivity.This unit applies to the fusion and embossing of inflatable toys, slippers, handbags, purses, belts, bags, stationery, stickers, trademarks, PVC tapes, etc. Language Option Switch languge to help reading: French German Italian Russian Spanish Portuguese French German Italian Russian Spanish Portuguese
